Our precision curved guides are engineered to deliver ultra-smooth circular motion with micron-level accuracy, making them ideal for robotic welding, semiconductor handling, and automated assembly applications.
Key Technical Specifications
✔ Radius Options - Customizable from 200mm to 5000mm diameter
✔ Load Capacity - Supports up to 50kg dynamic load per carriage
✔ Surface Treatment - Special chromium plating for corrosion resistance (HRC 58-62)
✔ Lubrication System - Integrated grease grooves for maintenance-free operation
✔ Mounting Flexibility - Multiple flange configurations for easy integration
Industry-Leading Performance Features
Zero-Backlash Design - Preloaded angular contact bearings eliminate play
Thermal Stability - Special alloy composition minimizes thermal expansion
Low Noise Operation - Optimized recirculation path (<55dB)
High Rigidity - Reinforced rail structure withstands moment loads
Critical Applications in Growth Industries
EV Battery Production - Precise electrode handling in circular formation processes
Medical Device Assembly - Sterilizable models for cleanroom environments
Aerospace Manufacturing - Reliable performance in vibration-intensive applications
Packaging Machinery - High-speed rotary indexing with positional accuracy
Advanced Manufacturing Process
Each guide undergoes:
CNC Profile Grinding - Achieves Ra 0.2μm surface finish
Cryogenic Treatment - Enhances dimensional stability
Laser Alignment Testing - Verifies circularity within 5μm TIR
72-Hour Endurance Testing - Simulates 5-year operational lifespan
